| Main Specifications | |
| Series | SuperServer |
| Supported Processor | Intel Xeon Scalable Processors |
| Memory Technology | DDR4 ECC Reg |
| Chipset | Intel C622 chipset |
| Form Factor | 1U |
| Color | Black |
| Detailed Specifications | |
| Memory Slots | 6x 288-pin DIMM Sockets |
| Max Memory Support | Up to 1.5TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM |
| Graphics | ASPEED AST2500 BMC |
| Ethernet | Dual 10GBase-T LAN with Intel® X722 + X557 |
| Serial ATA | Intel® C622 controller; RAID 0, 1, 5, 10 |
| Power | 500W High-Efficiency Power Supply w/ PMBus 1.2, I2C, and PFC |
| External Bays | 2 Hot-swap 2.5″ drive bays |
| Internal Bays | 2 Internal 2.5″ SSD bays (optional) |
| M.2 | M.2: 1 M-Key 2280/22110 PCI-E 3.0 x4 and SATA |
| Expansion Slots | 2 PCI-E 3.0 x16 (FHFL) slots |
| Management | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Front Panel | Power On/Off button System Reset button Power LED Hard drive activity LED Network activity LEDs System Information LED |
| BIOS | AMI 32Mb SPI Flash ROM |
| Cooling | 6x 40x28mm PWM fans |
| Dimensions (WxHxD) | 17.2″ (437mm) x 1.7″ (43mm) x 15″ (381mm) |
| Gross Weight | 26 lbs (11.79 kg) |
| USB Ports | 2 USB 3.0 ports (front) 2 USB 2.0 ports (front) |
| Serial Ports | 1 COM port (front) |
| LAN Ports | 2 RJ45 10GBase-T LAN ports 1 RJ45 dedicated IPMI LAN port |
| SATA DOM | 2 SuperDOM (Disk on Module) ports with built-in power |
| Integrated Graphics | Yes |
| VGA Ports | 1 VGA port |
