SuperStorage 2029P-E1CR24H Storage (EOL)
TEKLİF AL
| Main Specifications | |
| Series | SuperStorage |
| Supported Processor | Intel Xeon Scalable Processors |
| System Bus | Dual UPI up to 10.4 GT/s |
| Memory Technology | DDR4 ECC Reg |
| Chipset | Intel C624 |
| Form Factor | 2U |
| Color | Black |
| Backplane | SAS3 12Gb/s direct attached storage backplane, w/ 24x SAS3 2.5″ drive slots |
| Detailed Specifications | |
| Memory Slots | 16x 288-pin DIMM Sockets |
| Max Memory Support | Up to 2TB ECC 3DS LRDIMM, 512GB ECC RDIMM, DDR4 up to 2666MHz |
| Graphics | ASPEED AST2500 BMC |
| Ethernet | Intel® X557 10GBase-T Ethernet Controller |
| Serial ATA | Intel® C624 controller for 10 SATA3 (6 Gbps) ports; RAID 0,1,5,10 |
| SAS | SAS3 (12Gbps) via Broadcom 3108 AOC; HW RAID RAID 0, 1, 5, 6, 10, 50, 60 |
| Power | 1200W Redundant Power Supplies with PMBus |
| External Bays | 24x Hot-swap 2.5″ SAS3/SATA3 drive bays 2x rear Hot-swap 2.5″ SATA3 drive bays 2x Optional Onboard NVMe M.2 |
| M.2 | 2x Optional Onboard NVMe M.2 |
| Expansion Slots | 3x PCI-E 3.0 x16 slot 4x PCI-E 3.0 x8 slots |
| Management | Support for Intelligent Platform Management Interface v.2.0 |
| Front Panel | Power On/Off button System Reset button Power status LED Hard drive activity LED Network activity LEDs System Overheat LED Power fail LED |
| BIOS | 256Mb AMI UEFI |
| Cooling | 3x Hot-swap 8cm redundant PWM cooling fans |
| Dimensions (WxHxD) | 17.2″ (437mm) x 3.5″ (89mm) x 24.8″ (630mm) |
| Gross Weight | 61 lbs (27.7 kg) |
| USB Ports | 4x USB 3.0 ports (rear), 1 Type A |
| Serial Ports | 1x Fast UART 16550 port / 1 Header |
| LAN Ports | 2x RJ45 10GBase-T ports 1x RJ45 Dedicated IPMI LAN port |
| M.2 Controller | Interace: PCIe 3.0 x4 and PCIe 3.0 x4 Form Factor: M-Key 22110 (RAID 0,1 support) |
| SATA DOM | 2x SATA-DOM connector (yellow color) |
| Integrated Graphics | Yes |
| VGA Ports | 1 |
| Trusted Platform Module | 1x TPM Header |
| Marka | Supermicro |
|---|---|
| Kategori | General Purpose Storage, Storage Server |
| Rackmount | 2U Rackmount |
| Sunucu Node Sayısı | 1 Node Server |
| Memory | 16 DIMM Slot |
| Disk Desteği | 24 Hot-Swap |
| HDD Slot | 2.5″ |
| Güç Kaynağı | Yedekli (Redundant) |
| Global SKU (Aktif Stok) | Hayır |
