Supermicro SuperServer SYS-E300-9A-4CN8 - Intel® Atom® C3558 - 1x 2.5" SATA - 1x M.2 - 4x DDR4 - 84W DC Power Adapter
IoT
SuperServer E300-9A-4CN8 Server
TEKLİF AL
Supermicro SuperServer SYS-E300-9A-4CN8 – Intel® Atom® C3558 – 1x 2.5″ SATA – 1x M.2 – 4x DDR4 – 84W DC Power Adapter
Form Faktör
1U
Bellek
4x DDR4 DIMM
Stok Sorunuz
Teslim süresi konfigürasyon ve stoğa göre — kesin süre teklifte
Teslim süreleri ürüne, güncel stok durumuna ve ithalat/gümrük süreçlerine göre değişir. Kesin teslim tarihi siparişten önce satış ekibimizce teyit edilir.
Yerinde Destek
Opsiyonel 24/7 Destek
Yerel Stok
Stoktaki ürünlerde öncelikli teslimat
Kurulum
opsiyonel
| Main Specifications | |
| Series | SuperServer |
| Supported Processor | Intel Atom C3558 |
| Memory Technology | DDR4 RDIMM and ECC/Non-ECC UDIMM |
| Chipset | System on Chip |
| Form Factor | Mini-1U |
| Color | Black |
| Detailed Specifications | |
| Memory Slots | 4x 288-pin DDR4 DIMM sockets |
| Max Memory Support | Supports up to 256GB DDR4 ECC RDIMM Supports up to 64GB DDR4 ECC/non-ECC UDIMM |
| Graphics | Aspeed AST2400 |
| Ethernet | Quad Gigabit Ethernet LAN via Intel® i350-AM4 Quad Gigabit Ethernet LAN via Marvell® Alaska® 88E1543 |
| Serial ATA | SoC controller for 4 SATA3 (6Gbps) ports |
| Power | 84W DC power adapter |
| Internal Bays | 1 fixed 2.5" drive bay when AOC area is not occupied |
| M.2 | 1 M.2 Key Interface: PCI-E 3.0 x2 Form Factor: B Key 3042/2280 |
| Expansion Slots | 1 PCI-E 3.0 x4 AOC slot (LP) |
| Front Panel | Power On/Off button Power LED (Hard drive activity LED) |
| BIOS | AMI UEFI |
| Cooling | 1x 40mm chassis fan |
| Dimensions (WxHxD) | 10" (254mm) x 1.7" (43mm) x 8.9" (226mm) |
| Gross Weight | 7.5 lbs (3.4 kg) |
| USB Ports | 2 USB 3.0 ports (rear) |
| LAN Ports | 8 RJ45 Gigabit Ethernet LAN ports 1 RJ45 Dedicated IPMI LAN port |
| SATA DOM | 1 SuperDOM (Disk on Module) power connector |
| VGA Ports | 1 VGA port |
| Trusted Platform Module | TPM 2.0 header |
Tüm Özellikler
| Marka | Supermicro |
|---|---|
| Kategori | IoT |
| Form Factor | Mini 1U |
| Processor | Intel® Atom® processor C3558 |
| Socket | Single Socket |
| Memory | 4 DIMM Slot |
| Disk Desteği | 1 Fixed 2.5" |
| HDD Slot | 2.5" |
| Güç Kaynağı | Yedeksiz (Single) |
| Global SKU (Aktif Stok) | Hayır |
| Form Faktör | 1U |
| Bellek Desteği | 4x DDR4 DIMM |
